D510r Harrison 500-series rack (UK/EU)

D510r 500-Series Rack System

The Harrison D510r is a high-end, ultra-flexible ten-slot 500 Series rack system, engineered for professionals who demand uncompromising audio performance and modular versatility. Built upon the same sonic legacy that helped shape the sound of Michael Jackson, Led Zeppelin, and Steely Dan, the D510r embodies Harrison’s signature blend of precision engineering and musical warmth.

Versatile and Expandable

Designed for the modern hybrid workflow, the D510r forms the foundation of the Harrison D510 modular ecosystem. Combine it with the D510mx summing mixer and your choice of D510ua USB/ADAT or D510dante AoIP interface cards to create the ultimate 500 Series recording and mixing platform — equally at home in world-class studios, live sound rigs, or mobile production setups.

High-performance Tracking & Analogue Summing

Experience the renowned Harrison soundstage and depth through true analogue summing. Pair the D510r with eight 32Cpre+ mic preamps to build a powerful portable recording rig, or integrate EQ and dynamics modules to create a custom eight-channel Harrison mixer — all within a compact 3U chassis. Whether adding warmth and cohesion to digital stems, summing drum machines and samplers, or achieving console-grade tracking on the go, the D510r adapts seamlessly to your creative workflow.

Built to perform

Crafted for durability and reliability, the D510r’s rugged steel chassis fits a standard 19” rack and is built to handle the rigours of both touring and studio use. Its integrated high-performance power supply delivers 30% more power per module than the standard 500 Series specification, providing exceptional stability, headroom, and performance — ensuring every module operates at its full potential.

The Harrison D510r is more than a rack — it’s a foundation for creative expansion, designed to evolve with your music.

Technical Specifications

• Dimensions:

  • Length (L): Standard 19” (48.26 cm)

  • Height (H): 3RU 5.25” (13.34 cm)

  • Depth (D): 7.2” (18.29 cm)

• Power Input: 50/60Hz / 80-246VAC / 1.8 -0.55A

• Power Per Slot: 170ma

• Weight: 10.4 LBS (4.72kg)

• Optional D510mx analogue summing mixer card, D510dante interface card, and
• USB+ADAT interface card (currently under development)
